Author: Mike Verney, Area Sales Manager, JS Air Curtains

Benefits of air curtains on cold stores

With the continuous need for cold store businesses to cut costs while maintaining productivity, a correctly selected air curtain can help a cold store operator to achieve this and more.

Air curtains can greatly reduce the energy loss of a cold store by keeping the chilled air in and warm air out with the door open and in use. Temperature recordings can show an increase of between 4°C and 10°C every time a cold store door is opened. This can be improved to 1°C with an air curtain, which results in reducing heat loss by up to 90%.

An air curtain can be mounted horizontally across the top of a doorway or vertically to the side of the entrance and should be positioned as close to the opening as possible. This will create an air barrier across a doorway and provide an effective seal between two temperature zones, whilst allowing unhindered access and vision into the cold store.

As the air curtain keeps the chilled air inside the cold store, the load on refrigeration equipment is reduced along with the associated energy consumption and carbon footprint. As the cooling equipment does not need to work as hard, its overall operational lifetime is increased.

Forklift operators are able to remain in their cabs saving time while also improving safety...

By reducing hot spots near the entrance a more consistent temperature is maintained which prevents product spoilage from pallets placed near the doorway. This, in turn, increases the useable space in a cold store leading to a more profitable operation.

Air curtains enable cold store doors to remain open allowing people and vehicles unhindered access. This improves the speed of operations around the cold store as forklift operators do not need to dismount from the cab, push a button to open a roller-shutter door and get back in the cab before driving through.

The positioning of air curtains means drivers are less likely to damage the units and because air curtains do not have the same wear and tear as roller-shutter doors, money is saved on expensive repair bills.

For people who are working in external areas close to the cold store, an air curtain will increase their comfort and productivity level, as cold air leakage by the door is greatly reduced when it is open.

Horizontally mounted air curtain installed above the doorway to create an air barrier across the entrance...

Air curtain systems also improve safety around the entrance as they remove the need for plastic slats or fast acting roller-shutter doors, enabling people to clearly see if anyone or anything is exiting or entering the cold store. Also, the misting that occurs as warm air floods into a cold store is greatly reduced along with any ice build-up on the floor near the entrance, both of which can lead to potential accidents.

As well as reducing unwanted hot air infiltration, air curtains are also very effective at discouraging pests such as rats, mice or flying insects from entering a doorway and for keeping out dust, smoke and fumes.

An air curtain will help to maintain the temperature in the cold store to the specific levels required to keep products in an ideal environment. This is especially critical in the food sector where quality control and precise temperature controls are vital.
